GL Heat Shrink End Caps 12.7-2.4mm x 22mm 100Pk

RENF12-3

$44.76
In Stock


Shipping

Free Delivery Australia wide for all orders - Minimum invoice value $50


Product: 12.7mm ID to 2.4mm ID x 38mm Length
Heat Shrink – RENF Low Cost Semi-ridgid Adhesive Lined End Caps

Applications:
Provides sealing and protection of cable ends for power cables to 1kV and irrigation / reticulation cables.

General:

  • Resistance to chemical, fuel oil, insulation oil, copper corrosion and fungus
  • Hot melt adhesive for effective water and environmental sealing
  • High tensile strength
  • UV stabilised
RENF Heat Shrink End Cap Circular Dimensions
Part Number

As Supplied After Recovery
Inside Ø Inside Ø Wall
RENF3-1 3.2mm ≤ 0.80mm 1.20mm
RENF5-2 4.8mm ≤ 1.30mm 1.52mm
RENF6-2 6.4mm ≤ 1.52mm 1.91mm
RENF9-2 9.5mm ≤ 2.00mm 2.08mm
RENF12-3 12.7mm ≤ 2.41mm 2.54mm



(RENF12-3)


RENF End Caps Testing Method Requirement
 Physical  Tensile Strength ASTM D 2671 10.4MPa
Elongation % ASTM D 2671 ≥300
Tensile Strength
After Aging MPa
UL224
158°C x 168hrs
7.3
Elongation %
After Aging
UL224
158°C x 168hrs
≥200
Electrical Dielectric Strength kV/mm IEC 243 15
Volume Resistance Ohm/cm  ASTM-D-876 2.5x1014
Adhesive Water Absorption ASTM D 570 <0.2%
Softening Point ASTM DE 28 90°C +/-5%
Strength of Pearing (PE) ASTM D 1000 120N/25mm
Strength of Pearing ASTM D 1000 80N/25mm



SKU RENF12-3
Brand Radiform
