Bi Metal Lug to suit 95mm² Aluminium M10 Stud
BML95-10
$10.64
Sold Out - Backorder Available
Shipping
Free Delivery Australia wide for all orders - Minimum invoice value $50
Notify me when back in stock
Bi-metal Compression Lug 95mm²
Use Australian standard compression tooling only
| Part Number | Palm Width | Barrel Length | Overall Length | Hex Die Across Flats |
|---|---|---|---|---|
| BML16 | 20mm | 32mm | 75mm | 9mm |
| BML25 | 20mm | 32mm | 75mm | 9mm |
| BML35 | 20mm | 32mm | 75mm | 9mm |
| BML50 | 24mm | 32mm | 75mm | 13.2mm |
| BML70 | 24mm | 32mm | 75mm | 13.2mm |
| BML95 | 24mm | 60mm | 115mm | 17.3mm |
| BML120 | 30mm | 60mm | 115mm | 17.3mm |
| BML150 | 30mm | 60mm | 120mm | 22mm |
| BML185 | 35mm | 60mm | 120mm | 22mm |
| BML240 | 35mm | 60mm | 135mm | 28.4mm |
| BML300 | 36mm | 60mm | 135mm | 28.4mm |
| BML400 | 50mm | 70mm | 165mm | 39mm |
| BML500 | ||||
| BML630 |
(BML95)
AS/NZS 4325.1:1995 (Reconfirmed 2016)
| SKU | BML95 |
| Brand | HellermannTyton |
